Name: Дънна платка, ASUS PRIME B550-PLUS /AM4
Brand: ASUS
SKU: 90MB14U0-M0EAY0
Price: 99.07 EUR
Availability: InStock

☎ 0886 177 222 ✉ info@xtreme.bg

Доставка· Условия· Рекламация· Контакти·

Вход

⇆Сравни ⚙Сглоби PC Количка

ASUS

Цена

€99⁰⁷ / 193⁷⁶ лв

с ДДС

* ВЪНШЕН ДОСТАВЧИК - (1 до 3 дни)

* - Стоката е в склад на официалния вносител на марката за България. Времето за доставка е обикновено от 1 до 3 работни дни. Възможно е към момента на завършване на поръчката, продукта да е вече изчерпан. В случай на изчерпана наличност ще се свържем с Вас

К-во:

Добави в Количката

Удължи гаранцията си

+1 година: + 13€

+2 години: + 19€

Код: 90MB14U0-M0EAY0
Категория: Дънни Платки
Гаранция: 3 Години

РЕЙТИНГ

ТВОЯ РЕЙТИНГ

Мнения

Информираме Ви, че въпреки нашите усилия не можем да гарантираме, че публикуваната информация и снимки не съдържат неточности или грешки, които не могат да бъдат правно основание за претенции.

Описание
Детайли
Мнения
ИИ Описание

Vendor_url

https://www.asus.com/Motherboards/PRIME-B550-PLUS/specifications/

Graphics

1 x DisplayPort 1.2 *

1 x HDMI 2.1(4K@60HZ)

Chipset

AMD B550

Expansion slots

3rd Gen AMD Ryzen™ Processors: 1 x PCIe 4.0 x16 (x16 mode)

AMD B550 Chipset: 1 x PCIe 3.0 x16 (x4 mode)

3 x PCIe 3.0 x1 *1

Storage

Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports

3rd Gen AMD Ryzen™ Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode)

AMD B550 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*2

6 x SATA 6Gb/s port(s), *2

Support Raid 0, 1, 10

Memory type

4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory * Next Generation AMD Ryzen PRO Processors

4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory Dual Channel Memory Architecture

Rear panel I/O

1 x DisplayPort

1 x HDMI

1 x LAN (RJ45) port(s)

2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C®)

4 x USB 3.2 Gen 1 (blue) Type-A

2 x USB 2.0

1 x Optical S/PDIF out

5 x Audio jack(s)

Connectors

1 x CPU Fan connector(s)

1 x CPU OPT Fan connector(s)

3 x Chassis Fan connector(s)

1 x AIO_PUMP connector

2 x Aura RGB Strip Headers

1 x Addressable Gen 2 header(s)

1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)

2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)

1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode)

1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)

1 x SPI TPM header

6 x SATA 6Gb/s connector(s)

1 x Thunderbolt header(s)

1 x 24-pin EATX Power connector(s)

1 x 8-pin EATX 12V Power connectors

1 x Front panel audio connector(s) (AAFP)

1 x Thermal sensor connector(s)

1 x Clear CMOS jumper(s)

1 x System panel connector

1 x COM port header

Audio

Realtek ALC887 7.1-Channel High Definition Audio CODEC

- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback

Audio Feature : - Optical S/PDIF out port(s) at back panel

- LED-illuminated design

- Audio Shielding

- Dedicated audio PCB layers

- Premium Japanese audio capacitors

- Unique de-pop circuit

Lan

Realtek® RTL8111H

ASUS LANGuard

BIOS

256 Mb Flash ROM, UEFI AMI BIOS

Form factor

ATX Form Factor

12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

Windows® 10 64-bit

Warranty

36 Months

Атрибут	Стойност
Vendor_url	https://www.asus.com/Motherboards/PRIME-B550-PLUS/specifications/
Chipset	AMD B550
OS	Windows® 10 64-bit
Warranty	36 Months
CPU's supported	Build in AMD AM4 Socket 3rd Gen AMD Ryzen™ Processors *
Memory type	4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory * Next Generation AMD Ryzen PRO Processors
Memory type	4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory Dual Channel Memory Architecture
Form Factor	ATX Form Factor
Form Factor	12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Audio	- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
Audio	- Dedicated audio PCB layers
Audio	- Audio Shielding
Audio	- Premium Japanese audio capacitors
Audio	Realtek ALC887 7.1-Channel High Definition Audio CODEC
Audio	Audio Feature : - Optical S/PDIF out port(s) at back panel
Audio	- LED-illuminated design
Audio	- Unique de-pop circuit
Rear panel I/O	1 x DisplayPort
Rear panel I/O	1 x HDMI
Rear panel I/O	1 x LAN (RJ45) port(s)
Rear panel I/O	4 x USB 3.2 Gen 1 (blue) Type-A
Rear panel I/O	2 x USB 2.0
Rear panel I/O	2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C®)
Rear panel I/O	1 x Optical S/PDIF out
Rear panel I/O	5 x Audio jack(s)
LAN	ASUS LANGuard
LAN	Realtek® RTL8111H
Expansion Slots	3rd Gen AMD Ryzen™ Processors: 1 x PCIe 4.0 x16 (x16 mode)
Expansion Slots	AMD B550 Chipset: 1 x PCIe 3.0 x16 (x4 mode)
Expansion Slots	3 x PCIe 3.0 x1 *1
Graphics	1 x HDMI 2.1(4K@60HZ)
Graphics	1 x DisplayPort 1.2 *
BIOS	256 Mb Flash ROM, UEFI AMI BIOS
I/O	1 x DisplayPort
I/O	2 x USB 2.0
I/O	1 x HDMI
I/O	1 x LAN (RJ45) port(s)
I/O	4 x USB 3.2 Gen 1 (blue) Type-A
I/O	2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C®)
I/O	1 x Optical S/PDIF out
I/O	5 x Audio jack(s)
Storage	Support Raid 0, 1, 10
Storage	Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Storage	3rd Gen AMD Ryzen™ Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode)
Storage	AMD B550 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*2
Storage	6 x SATA 6Gb/s port(s), *2
Connectors	1 x SPI TPM Header
Connectors	1 x CPU Fan connector(s)
Connectors	1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
Connectors	2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Connectors	1 x 24-pin EATX Power connector(s)
Connectors	1 x 8-pin EATX 12V Power connectors
Connectors	1 x Front panel audio connector(s) (AAFP)
Connectors	1 x Clear CMOS jumper(s)
Connectors	1 x System panel connector
Connectors	1 x COM port header
Connectors	1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
Connectors	6 x SATA 6Gb/s connector(s)
Connectors	1 x CPU OPT Fan connector(s)
Connectors	2 x Aura RGB Strip Headers
Connectors	1 x Addressable Gen 2 header(s)
Connectors	3 x Chassis Fan connector(s)
Connectors	1 x AIO_PUMP connector
Connectors	1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode)
Connectors	1 x Thunderbolt header(s)
Connectors	1 x Thermal sensor connector(s)
Тегло	0.00кг

Дънна платка ASUS PRIME B550-PLUS (AM4)

Извлечете максимума от вашия AMD Ryzen процесор с ASUS PRIME B550-PLUS. Тази ATX дънна платка предлага стабилно захранване, поддръжка на PCIe 4.0 и ефективно охлаждане за безупречна работа при игри и продуктивност.

Ключови Предимства

PCIe 4.0 — Съвместимост с най-новите видеокарти и SSD дискове за изключително бърз трансфер на данни.
Стабилно захранване — 8+2 фази с ProCool конектори осигуряват надеждно захранване.
Цялостно охлаждане — Множество вентилаторни глави, радиатор за VRM и радиатор за M.2 поддържат ниски температури.

Технически Спецификации

Спецификация	Стойност
Сокет	AM4
Форм фактор	ATX
Чипсет	AMD B550
Тип памет	DDR4
Слотове за памет	4
Максимална памет	128 GB
M.2 слотове	2
SATA портове	6
PCIe x16 слотове	2
Скорост на LAN	1 Gbps
USB-C портове	1
RGB подсветка	Не
